| Uimhir Pháirt | HV550QUB-H13 |
| Branda | BOE |
| Méid | 55 |
| Iarratas | TV Sets |
| Rún | 38403×2160 |
| Comhdhéanamh | a-Si TFT-LCD , CELL |
| Gile | |
| CR | 1200:1 |
| Dathanna | 1.07B |
| Cúlsolas | No |
| Comhéadan | V-by-One |
| branda painéil | BOE |
| méid an phainéil | 55" |
| taifeach | 3840(3)×2160, UHD, 80PPI |
| limistéar taispeána | 1209.6(W)×680.4(H) mm |
| méid imlíne | 1225.2(W)×696.7(H) ×1.34(D) mm |
| gile | 0 cd/m² |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| doimhneacht gloine | 0.50+0.50 mm |
| dathanna a thaispeáint | 1.07B 73% NTSC |
| minicíocht | 120Hz |
| Tiománaí ic | COF Built-in 6 source chips |
| meáchan painéal | 2.60Kgs (Typ.) |
| comhéadan comhartha | V-by-One 8 lane , 60 pins Connector |
| voltas ionchuir | 12.0V (Typ.) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| múnla painéil | HV550QUB-H13 |
| cineál painéil | a-Si TFT-LCD , CELL |
| formáid picteilín | RGBW Vertical Stripe |
| oscailt bezel | - |
| dromchla | Antiglare (Haze 1%), Hard coating (3H) |
| cóimheas codarsnachta | 1200:1 (Typ.) (TM) |
| mód taispeána | ADS, Normally Black, Transmissive |
| am freagartha | 8 (Typ.)(G to G) |
| transmissivity | 7.15% (Typ.)(with Polarizer) |
| cineál lampa | No B/L |
| scáileán tadhaill | Without |
| iarratas | TV Sets |
