| Uimhir Pháirt | HT12X21-230 |
| Branda | HYDIS |
| Méid | 12.1 |
| Iarratas | PAD |
| Rún | 1024×768 |
| Comhdhéanamh | LCM |
| Gile | 180 |
| CR | 450:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | LVDS |
| branda painéil | BOE HYDIS |
| múnla painéil | HT12X21-230 2 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 12.1 inch |
| taifeach | 1024(RGB)×768 , XGA |
| mód taispeána | AFFS, Normally Black, Transmissive |
| limistéar gníomhach | 245.76×184.32 mm |
| imlíne | 270×199×7 mm |
| dromchla | Antiglare (Haze 25%), Hard coating (3H) |
| gile | 180 cd/m² (Typ.) |
| cóimheas codarsnachta | 450:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193140% |
| am freagartha | 40 (Typ.)(Tr+Td) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 1 pcsCCFLWithout Driver |
| comhéadan comhartha | LVDS (1 ch, 6-bit), 20 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | PAD |
