| Uimhir Pháirt | HSD170PUW1-B00 |
| Branda | HannStar |
| Méid | 17.0 |
| Iarratas | Laptop |
| Rún | 1920×1200 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| branda | HannStar |
| Mionsamhail | HSD170PUW1-B00 |
| méid trasnánach | 17.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1920(RGB)×1200 [WUXGA] 133PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 365.184(H)×228.24(V) mm |
| imlíne dim. | 373.248(H)×241.38(V) ×6(D) mm |
| limistéar bezel | - |
| cóireáil | Antiglare |
| luminance | 270 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| modh oibriúcháin | IPS Pro, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 95% DCI-P3 |
| foinse solais | WLED , 15K hours , With LED Driver |
| stíl fhoirm | - |
| deartha le haghaidh | Laptop |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | eDP (2 Lanes) , eDP1.3 , 30 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| B170UW02 V0 | AUO | 17.0 | 1920×1200 |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ5 | LG Display | 17.0 | 1280×1024 |
| LTM170E8-L01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTN170BT06-G01 | Samsung | 17.0 | 1440×900 |
| M170E8-L01 | Innolux | 17.0 | 1280×1024 |
| M170EG02 V3 | AUO | 17.0 | 1280×1024 |
| M170EP01 V2 | AUO | 17.0 | 1280×1024 |
