| Uimhir Pháirt | HSD170MGW1-B00 |
| Branda | HannStar |
| Méid | 17.0 |
| Iarratas | DMPC |
| Rún | 1440×900 |
| Comhdhéanamh | LCM |
| Gile | 250 |
| CR | 600:1 |
| Dathanna | 16.2M |
| Cúlsolas | CCFL |
| Comhéadan | LVDS |
| branda painéil | HannStar |
| múnla painéil | HSD170MGW1-B00 1 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 17.0 inch |
| taifeach | 1440(RGB)×900 , WXGA+ |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 367.2×229.5 mm |
| imlíne | 389.2×254.5×11.8 mm |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 250 cd/m² (Typ.) |
| cóimheas codarsnachta | 600:1 (Typ.) |
| dathanna a thaispeáint | 16.2M (6-bit + FRC), CIE193163% |
| am freagartha | 3/5 (Typ.)(Tr/Td) |
| uillinn féachana | 80/80/65/85 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 2 pcsCCFLWithout Driver |
| comhéadan comhartha | LVDS (2 ch, 8-bit), 30 pins |
| voltas ionchuir | 5.0V (Typ.) |
| iarratas | DMPC |
