| Uimhir Pháirt | HSD123KPW2-A10 |
| Branda | HannStar |
| Méid | 12.3 |
| Iarratas | Automotive Display |
| Rún | 1920×720 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1100:1 |
| Dathanna | 16.7M |
| Cúlsolas | 11S4P |
| Comhéadan | LVDS |
| monaróir | HannStar |
| méid scáileáin | 12.3 inch |
| uimhir picteilín | 1920(RGB)×720 167PPI |
| limistéar gníomhach(mm) | 292.032 × 109.512 (H×V) |
| limistéar bezel (mm) | 294.8 × 112.1 (H×V) |
| luminance | 850 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M 70% NTSC |
| mais | TBD |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (2 ch, 8-bit) , 50 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| ainm samhail | HSD123KPW2-A10 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 308.1 × 130 × 15.6 (H×V×D) |
| cóireáil | Glare (Haze 0%) |
| cóimheas codarsnachta | 1100 : 1 (Typ.) (TM) |
| freagra | 16/14 (Typ.)(Tr/Td) ms |
| modh oibre | IPS Pro, Normally Black, Transmissive |
| cúlsolas | 11S4P WLED , 30K hours , No Driver |
| a úsáidtear le haghaidh | Automotive Display |
| scáileán tadhaill | Without |
