| Uimhir Pháirt | HSD123JPW1-A20 |
| Branda | HannStar |
| Méid | 12.3 |
| Iarratas | Outdoor High Brightn |
| Rún | 1920×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 11S4P |
| Comhéadan | LVDS |
| branda painéil | HannStar |
| múnla painéil | HSD123JPW1-A20 |
| méid an phainéil | 12.3" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1920(RGB)×720, 167PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 292.032(W)×109.512(H) mm |
| oscailt bezel | 294.8(W)×112.1(H) mm |
| méid imlíne | 308.1(W)×130(H) ×16.6(D) mm |
| dromchla | Antiglare |
| gile | 850 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | IPS Pro, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 18/17 (Typ.)(Tr/Td) |
| dathanna a thaispeáint | 16.7M 70% NTSC |
| cineál lampa | 11S4P WLED , 30K hours , Without Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | 520g (Typ.) |
| iarratas | Outdoor High Brightness Automotive Display |
| comhéadan comhartha | LVDS (2 ch, 8-bit) , 50 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
