| Uimhir Pháirt | HSD121KXN1-A10-0299 |
| Branda | HannStar |
| Méid | 12.1 |
| Iarratas | Automotive Display |
| Rún | 1024×768 |
| Comhdhéanamh | CELL, a-Si TFT-LCD |
| Gile | |
| CR | 900:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | No |
| Comhéadan | LVDS |
| monaróir | HannStar |
| ainm samhail | HSD121KXN1-A10-0299 |
| méid scáileáin | 12.1 inch |
| cineál scáileáin | CELL, a-Si TFT-LCD |
| uimhir picteilín | 1024(RGB)×768 (XGA) 105PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 245.76 × 184.32 (H×V) |
| imlíne (mm) | 256.18 × 196.9 × 1.27 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 0 cd/m² |
| cóimheas codarsnachta | 900 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 30 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS Pro, Normally Black, Transmissive |
| tiús gloine | 0.50+0.50 mm |
| transmissivity | - |
| doimhneacht dath | 262K/16.7M 70% NTSC |
| cúlsolas | No B/L , No Driver |
| mais | 160/180g (Typ./Max.) |
| a úsáidtear le haghaidh | Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
