| Uimhir Pháirt | HSD104KXN1-A20 |
| Branda | HannStar |
| Méid | 10.4 |
| Iarratas | Automotive Display |
| Rún | 1024×768 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 900:1 |
| Dathanna | 262K/16.2M |
| Cúlsolas | WLED |
| Comhéadan | |
| monaróir | HannStar |
| ainm samhail | HSD104KXN1-A20 |
| méid scáileáin | 10.4 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1024(RGB)×768 (XGA) 123PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 211.2 × 158.4 (H×V) |
| imlíne (mm) | - |
| luminance | - |
| cóimheas codarsnachta | 900 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | - |
| radharc maith ag | Symmetry |
| modh oibre | IPS Pro, Normally Black, Transmissive |
| doimhneacht dath | 262K/16.2M |
| cúlsolas | WLED |
| mais | - |
| a úsáidtear le haghaidh | Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
