| Uimhir Pháirt | HSD103JPW2-H10 |
| Branda | HannStar |
| Méid | 10.3 |
| Iarratas | Outdoor High Brightn |
| Rún | 1920×720 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1500:1 |
| Dathanna | 16.7M |
| Cúlsolas | 4 |
| Comhéadan | LVDS |
| monaróir | HannStar |
| méid scáileáin | 10.3 inch |
| uimhir picteilín | 1920(RGB)×720 200PPI |
| limistéar gníomhach(mm) | 243.648 × 91.368 (H×V) |
| limistéar bezel (mm) | 246.7 × 94.4 (H×V) |
| luminance | 1000 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M 70% NTSC |
| mais | TBD |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (2 ch, 8-bit) , 60 pins FPC |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| ainm samhail | HSD103JPW2-H10 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 258.8 × 110 × 17 (H×V×D) |
| cóireáil | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 1500 : 1 (Typ.) (TM) |
| freagra | 30 (Max.)(Tr+Td) ms |
| modh oibre | IPS Pro, Normally Black, Transmissive |
| cúlsolas | 4 strings WLED , 20K hours , No Driver |
| a úsáidtear le haghaidh | Outdoor High Brightness Automotive Display |
| scáileán tadhaill | Without |
