| Uimhir Pháirt | HSD103IPW1-A10-0299 |
| Branda | HannStar |
| Méid | 10.3 |
| Iarratas | Automotive Display |
| Rún | 1280×480 |
| Comhdhéanamh | CELL, a-Si TFT-LCD |
| Gile | |
| CR | 900:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | No |
| Comhéadan | |
| monaróir | HannStar |
| ainm samhail | HSD103IPW1-A10-0299 |
| méid scáileáin | 10.3 inch |
| cineál scáileáin | CELL, a-Si TFT-LCD |
| uimhir picteilín | 1280(RGB)×480 (DVGA) 133PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 243.84 × 91.44 (H×V) |
| imlíne (mm) | 253 × 103.3 × 1.25 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 0 cd/m² |
| cóimheas codarsnachta | 900 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 30 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS Pro, Normally Black, Transmissive |
| tiús gloine | 0.50+0.50 mm |
| transmissivity | 4.7% (Typ.)(with Polarizer) |
| doimhneacht dath | 262K/16.7M 70% NTSC |
| cúlsolas | No B/L |
| mais | TBD |
| a úsáidtear le haghaidh | Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
