| Uimhir Pháirt | HSD101PUW1-E00 |
| Branda | HannStar |
| Méid | 10.1 |
| Iarratas | Pad & Tablet |
| Rún | 1920×1200 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | MIPI |
| branda | HannStar |
| méid trasnánach | 10.1 inch |
| formáid picteilín | 1920(RGB)×1200 [WUXGA] 225PPI |
| limistéar gníomhach | 216.576(H)×135.36(V) mm |
| luminance | - |
| treo amharc | Symmetry |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 50% NTSC |
| meáchan | - |
| ráta fhráma | 60Hz |
| cineál comhéadan | MIPI (4 data lanes) , 39 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Mionsamhail | HSD101PUW1-E00 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | - |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| am freagartha | 25 (Typ.)(Tr+Td) |
| modh oibriúcháin | IPS Pro, Normally Black, Transmissive |
| foinse solais | WLED , 10K hours |
| deartha le haghaidh | Pad & Tablet |
| painéal tadhaill | Without |
