| Uimhir Pháirt | HSD101JFW1-C11 |
| Branda | HannStar |
| Méid | 10.1 |
| Iarratas | Automotive Display |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.2M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | HannStar |
| Mionsamhail | HSD101JFW1-C11 |
| méid trasnánach | 10.1 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1024(RGB)×600 [WSVGA] 117PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 222.72(H)×125.28(V) mm |
| imlíne dim. | 235(H)×143(V) ×6.3(D) mm |
| limistéar bezel | 226(H)×128.5(V) mm |
| cóireáil | Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| modh oibriúcháin | IPS Pro, Normally Black, Transflective |
| dath tacaíochta | 16.2M 45% NTSC |
| foinse solais | WLED [6S7P] , 20K hours , W/O Driver |
| meáchan | 265/275g (Typ./Max.) |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 60 pins FPC |
| soláthar leictreachas | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| A101AIE40L0 | Aptus | 10.1 | 1280×720 |
| B101AW01 V0 HW5A | AUO | 10.1 | 1024×576 |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| BP101WX1-200 | BOE | 10.1 | 1280×800 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| HE101NA-02C | Innolux | 10.1 | 1280×800 |
| HSD101PFW3-D00 | HannStar | 10.1 | 1024×600 |
| LTN101NT02-B01 | Samsung | 10.1 | 1024×600 |
| TV101QUM-N00 | BOE | 10.1 | 3840×2160 |
| YX101GL-01A | SEBO | 10.1 | 1280×800 |
