| Uimhir Pháirt | HSD090IHW1-A11 |
| Branda | HannStar |
| Méid | 9.0 |
| Iarratas | Automotive Display |
| Rún | 1280×720 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda painéil | HannStar |
| méid an phainéil | 9.0" |
| taifeach | 1280(RGB)×720, WXGA, 163PPI |
| limistéar taispeána | 198.912(W)×111.888(H) mm |
| méid imlíne | 210.7(W)×124.1(H) mm |
| gile | 600 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 70% NTSC |
| minicíocht | 60Hz |
| meáchan | - |
| múnla painéil | HSD090IHW1-A11 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | Antireflection |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| mód taispeána | IPS Pro, Normally Black, Transmissive |
| am freagartha | 30 (Typ.)(Tr+Td) |
| cineál lampa | WLED |
| scáileán tadhaill | Without |
| iarratas | Automotive Display |
