| Uimhir Pháirt | HSD080JHW3-A11 |
| Branda | HannStar |
| Méid | 8.0 |
| Iarratas | Outdoor High Brightn |
| Rún | 1280×720 |
| Comhdhéanamh | , a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| monaróir | HannStar |
| ainm samhail | HSD080JHW3-A11 |
| méid scáileáin | 8.0 inch |
| cineál scáileáin | , a-Si TFT-LCD |
| uimhir picteilín | 1280(RGB)×720 (WXGA) 184PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 176.64 × 99.36 (H×V) |
| imlíne (mm) | - |
| limistéar bezel (mm) | - |
| cóireáil | Antireflection |
| luminance | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 17/18 (Typ.)(Tr/Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS Pro, Normally Black, Transmissive |
| doimhneacht dath | 262K/16.7M |
| cúlsolas | WLED , No Driver |
| mais | - |
| a úsáidtear le haghaidh | Outdoor High Brightness Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| AT080TN01 | Innolux | 8.0 | 800×480 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| EJ080NA-04A | Innolux | 8.0 | 1024×768 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| LQ080T3AG01 | SHARP | 8.0 | 480×234 |
| LQ080Y5DW30 | SHARP | 8.0 | 800×480 |
| LSL080AL02-002 | Samsung | 8.0 | 800×1280 |
| PW080XU4 | E Ink | 8.0 | 480×220 |
| TX20D28VM2BAB | KOE | 8.0 | 800×480 |
