| Uimhir Pháirt | HSD070JDW6-A00 |
| Branda | HannStar |
| Méid | 7.0 |
| Iarratas | Automotive Display |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | HannStar |
| méid trasnánach | 7.0 inch |
| formáid picteilín | 800(RGB)×480 [WVGA] 133PPI |
| limistéar gníomhach | 152.4(H)×91.44(V) mm |
| limistéar bezel | 154.4(H)×93.44(V) mm |
| luminance | 1000 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 70% NTSC |
| meáchan | 153±10g |
| ráta fhráma | 60Hz |
| Mionsamhail | HSD070JDW6-A00 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 165(H)×104.07(V) ×8.5(D) mm |
| cóireáil | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| am freagartha | 30 (Typ.)(Tr+Td) |
| modh oibriúcháin | IPS Pro, Normally Black, Transmissive |
| foinse solais | WLED [7S4P] , 30K hours , W/O Driver |
| deartha le haghaidh | Automotive Display |
| painéal tadhaill | Without |
