| Uimhir Pháirt | HSD070IFW1-B10 |
| Branda | HannStar |
| Méid | 7.0 |
| Iarratas | Automotive Display |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda painéil | HannStar |
| méid an phainéil | 7.0" |
| taifeach | 1024(RGB)×600, WSVGA, 170PPI |
| limistéar taispeána | 153.6(W)×86.64(H) mm |
| gile | - |
| uillinn féachana | - |
| radharc is fearr ar | - |
| dathanna a thaispeáint | 16.7M |
| minicíocht | - |
| meáchan | - |
| múnla painéil | HSD070IFW1-B10 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | - |
| cineál lampa | WLED |
| scáileán tadhaill | Without |
| iarratas | Automotive Display |
