| Uimhir Pháirt | H546DLK01.0 |
| Branda | AUO |
| Méid | 5.5 |
| Iarratas | Mobile Phone |
| Rún | 1080×1920 |
| Comhdhéanamh | AM-OLED , OLED |
| Gile | |
| CR | 10000:1 |
| Dathanna | 16.7M |
| Cúlsolas | self |
| Comhéadan | MIPI |
| branda painéil | AUO |
| méid an phainéil | 5.5" |
| taifeach | 1080(RGB)×1920, FHD, 403PPI |
| limistéar taispeána | 68.04(W)×120.96(H) mm |
| méid imlíne | 70.84(W)×128.01(H) ×0.92(D) mm |
| gile | 350 cd/m² (Typ.) |
| uillinn féachana | 80/80/80/80 (Min.)(CR≥1600) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 100% NTSC |
| minicíocht | 100Hz |
| Tiománaí ic | COG Built-in RM69071 |
| meáchan painéal | - |
| comhéadan comhartha | MIPI (4 data lanes) |
| voltas ionchuir | 1.8/3.1/5.8/4.6/-2.9V (Typ.)(IOVCC/VCI/AVDD/OVDD/OVSS) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| múnla painéil | H546DLK01.0 |
| cineál painéil | AM-OLED , OLED |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | Hard coating (3H) |
| cóimheas codarsnachta | 10000:1 (Min.) (TM) |
| mód taispeána | - |
| am freagartha | - |
| cineál lampa | self |
| scáileán tadhaill | Embeded Touch |
| iarratas | Mobile Phone |
| H546DAN01.2 | AUO | 5.5 | 1080×1920 |
| H546DLB01.1 | AUO | 5.5 | 1080×1920 |
| LPM055A138A | JDI | 5.5 | 1440×2560 |
| LQ055T3SX02Z | SHARP | 5.5 | 1080×1920 |
| NL3224AC35-05 | NLT | 5.5 | 320×240 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| TM055JDHP71 | Tianma | 5.5 | 720×1280 |
