| Uimhir Pháirt | GV122WXM-N80 |
| Branda | BOE |
| Méid | 12.2 |
| Iarratas | Industrial |
| Rún | 1280×800 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| monaróir | BOE |
| ainm samhail | GV122WXM-N80 |
| méid scáileáin | 12.2 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 1280(RGB)×800 (WXGA) 123PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 262.656 × 164.16 (H×V) |
| imlíne (mm) | 278 × 184 × 9.91 (H×V×D) |
| limistéar bezel (mm) | 264.66 × 166.66 (H×V) |
| cóireáil | - |
| luminance | 450 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 30 (Typ.)(Tr+Td); 45 (Typ.)(G to G) ms |
| radharc maith ag | Symmetry |
| modh oibre | ADS, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 50% NTSC |
| cúlsolas | WLED , With LED Driver |
| mais | 564g (Typ.) |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 8-bit) , 30 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
