| Uimhir Pháirt | G238HAN01.1 |
| Branda | AUO |
| Méid | 23.8 |
| Iarratas | Industrial Medical I |
| Rún | 1920×1080 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 18S4P |
| Comhéadan | LVDS |
| monaróir | AUO |
| méid scáileáin | 23.8 inch |
| uimhir picteilín | 1920(RGB)×1080 (FHD) 92PPI |
| limistéar gníomhach(mm) | 527.04 × 296.46 (H×V) |
| limistéar bezel (mm) | 530.2 × 299.6 (H×V) |
| luminance | 400 cd/m² (Typ.) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M 70% NTSC |
| mais | 2.30Kgs (Typ.) |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (2 ch, 8-bit) , 30 pins Connector |
| soláthar voltais | 5.0V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ainm samhail | G238HAN01.1 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 543 × 317.4 × 11.65 (H×V×D) |
| cóireáil | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| freagra | 14 (Typ.)(G to G) ms |
| modh oibre | AHVA, Normally Black, Transmissive |
| cúlsolas | 18S4P WLED , 50K hours , No Driver |
| a úsáidtear le haghaidh | Industrial Medical Imaging |
| scáileán tadhaill | Without |
