| Uimhir Pháirt | G170ETN03.1 |
| Branda | AUO |
| Méid | 17.0 |
| Iarratas | Industrial |
| Rún | 1280×1024 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AUO |
| Mionsamhail | G170ETN03.1 |
| méid trasnánach | 17.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1280(RGB)×1024 [SXGA] 96PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 337.92(H)×270.336(V) mm |
| imlíne dim. | 358.5(H)×296.5(V) ×10.8(D) mm |
| limistéar bezel | 341.7(H)×274.1(V) mm |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | 3.8/1.2 (Typ.)(Tr/Td) |
| uillinn féachana | 85/85/80/80 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 16.7M 72% NTSC |
| foinse solais | WLED [9S4P] , 30K hours , W/O Driver |
| meáchan | 1.27Kgs (Typ.) |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (2 ch, 8-bit) , 30 pins Connector |
| soláthar leictreachas | 5.0V (Typ.) |
| timpeallacht | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| CLAA170EA07Q | CPT | 17.0 | 1280×1024 |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| G170ETN02.0 | AUO | 17.0 | 1280×1024 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LTA170D200F | TOSHIBA | 17.0 | 1280×1024 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-L01 | Samsung | 17.0 | 1920×1200 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
