| Uimhir Pháirt | G104VN01 V0 |
| Branda | AUO |
| Méid | 10.4 |
| Iarratas | IA |
| Rún | 640×480 |
| Comhdhéanamh | LCM |
| Gile | 450 |
| CR | 700:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | TTL |
| branda painéil | AUO |
| múnla painéil | G104VN01 V0 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 10.4 inch |
| taifeach | 640(RGB)×480 , VGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 211.2×158.4 mm |
| imlíne | 243×176.6×11.9 mm |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 450 cd/m² (Typ.) |
| cóimheas codarsnachta | 700:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193145% |
| am freagartha | 20/10 (Typ.)(Tr/Td) |
| uillinn féachana | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 2 pcsCCFLWithout Driver |
| comhéadan comhartha | CMOS (1 ch, 6-bit), 31 pins |
| voltas ionchuir | 3.3/5.0V (Typ.)(VCC) |
| iarratas | IA |
