| Uimhir Pháirt | G104STN01.4 |
| Branda | AUO |
| Méid | 10.4 |
| Iarratas | Industrial |
| Rún | 800×600 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 262K/16.2M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AUO |
| Mionsamhail | G104STN01.4 |
| méid trasnánach | 10.4 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 800(RGB)×600 [SVGA] 96PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 211.2(H)×158.4(V) mm |
| imlíne dim. | - |
| luminance | - |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | - |
| uillinn féachana | 80/80/60/70 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K/16.2M |
| foinse solais | WLED |
| meáchan | - |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 6/8-bit) |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
