| Uimhir Pháirt | G101STN01.D |
| Branda | AUO |
| Méid | 10.1 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| monaróir | AUO |
| méid scáileáin | 10.1 inch |
| uimhir picteilín | 1024(RGB)×600 (WSVGA) 117PPI |
| limistéar gníomhach(mm) | 222.72 × 125.28 (H×V) |
| limistéar bezel (mm) | 226.43 × 128.1 (H×V) |
| luminance | 450 cd/m² (Typ.) |
| uillinn féachana | 70/70/60/60 (Typ.)(CR≥10) |
| radharc maith ag | - |
| doimhneacht dath | 262K/16.7M 45% NTSC |
| mais | 180g (Typ.) |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| ainm samhail | G101STN01.D |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 235 × 143 × 5.2 (H×V×D) |
| cóireáil | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 500 : 1 (Typ.) (TM) |
| freagra | 7/9 (Typ.)(Tr/Td) ms |
| modh oibre | TN, Normally White, Transmissive |
| cúlsolas | WLED , 50K hours , With LED Driver |
| a úsáidtear le haghaidh | Industrial |
| scáileán tadhaill | Without |
