| Uimhir Pháirt | G101STN01.5 |
| Branda | AUO |
| Méid | 10.1 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| branda | AUO |
| méid trasnánach | 10.1 inch |
| formáid picteilín | 1024(RGB)×600 [WSVGA] 117PPI |
| limistéar gníomhach | 222.72(H)×125.28(V) mm |
| limistéar bezel | 226.43(H)×128.1(V) mm |
| luminance | 350 cd/m² (Typ.) |
| treo amharc | - |
| uillinn féachana | 70/70/60/60 (Typ.)(CR≥10) |
| dath tacaíochta | 262K/16.7M 45% NTSC |
| meáchan | 340g (Max.) |
| ráta fhráma | 60Hz |
| cineál comhéadan | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| soláthar leictreachas | 3.3/10/18/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| timpeallacht | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| Mionsamhail | G101STN01.5 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 235(H)×143(V) ×5.5(D) mm |
| cóireáil | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| am freagartha | 7/9 (Typ.)(Tr/Td) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| foinse solais | WLED , 15K hours , W/O Driver |
| deartha le haghaidh | Industrial |
| painéal tadhaill | Without |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| B101EAN01.1 | AUO | 10.1 | 1280×800 |
| B101EW01 V1 | AUO | 10.1 | 1280×720 |
| G101STN01.0 | AUO | 10.1 | 1024×600 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| G101STN01.3 | AUO | 10.1 | 1024×600 |
| HT101WSB-100 | BOE | 10.1 | 1024×600 |
| LP101WH1-TLA1 | LG Display | 10.1 | 1366×768 |
| M101NWT2 R1 | IVO | 10.1 | 1024×600 |
| N101BCG-GK1 | Innolux | 10.1 | 1366×768 |
