| Uimhir Pháirt | G101EAN02.2 |
| Branda | AUO |
| Méid | 10.1 |
| Iarratas | Industrial |
| Rún | 1280×800 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | AUO |
| múnla painéil | G101EAN02.2 |
| méid an phainéil | 10.1" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1280(RGB)×800, WXGA, 149PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 216.96(W)×135.6(H) mm |
| oscailt bezel | - |
| méid imlíne | 227.91(W)×148(H) ×7.75(D) mm |
| dromchla | Hard coating |
| gile | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| mód taispeána | AHVA, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 29 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 16.7M 50% NTSC |
| cineál lampa | WLED , 50K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | 290g (Max.) |
| iarratas | Industrial |
| comhéadan comhartha | LVDS (1 ch, 8-bit) , 40 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
