| Uimhir Pháirt | G101EAN02.1 |
| Branda | AUO |
| Méid | 10.1 |
| Iarratas | Industrial |
| Rún | 1280×800 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AUO |
| méid trasnánach | 10.1 inch |
| formáid picteilín | 1280(RGB)×800 [WXGA] 149PPI |
| limistéar gníomhach | 216.96(H)×135.6(V) mm |
| limistéar bezel | - |
| luminance | 400 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 50% NTSC |
| meáchan | 195g (Max.) |
| ráta fhráma | 60Hz |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 40 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
| Mionsamhail | G101EAN02.1 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 227.72(H)×147.8(V) ×4.8(D) mm |
| cóireáil | Hard coating |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| am freagartha | 29 (Typ.)(Tr+Td) |
| modh oibriúcháin | AHVA, Normally Black, Transmissive |
| foinse solais | WLED , 30K hours , With LED Driver |
| deartha le haghaidh | Industrial |
| painéal tadhaill | Without |
