| Uimhir Pháirt | G085VW01 V2 |
| Branda | AUO |
| Méid | 8.5 |
| Iarratas | IA |
| Rún | 800×480 |
| Comhdhéanamh | LCM |
| Gile | 200 |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | TTL |
| branda painéil | AUO |
| múnla painéil | G085VW01 V2 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 8.5 inch |
| taifeach | 800(RGB)×480 , WVGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 184.8×110.88 mm |
| imlíne | 222.7×135.4×12.5 mm |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 200 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193150% |
| am freagartha | 20/10 (Typ.)(Tr/Td) |
| uillinn féachana | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 1 pcsCCFLWithout Driver |
| comhéadan comhartha | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | IA |
