| Uimhir Pháirt | FC0802C00-FHYYBW-51LR |
| Branda | Fordata |
| Méid | 1.1 |
| Iarratas | Instruments & Me |
| Rún | 5×8 |
| Comhdhéanamh | STN-LCD, LCM |
| Gile | |
| CR | 10:1 |
| Dathanna | Monochrome |
| Cúlsolas | YG-LED |
| Comhéadan | 8-bit |
| branda | Fordata |
| Mionsamhail | FC0802C00-FHYYBW-51LR |
| méid trasnánach | 1.1 inch |
| cineál | STN-LCD, LCM |
| formáid charn | 5×8 dots |
| méid cló | 2.95×4.75 mm |
| páirc cló | 3.35×5.15 mm |
| limistéar gníomhach | 26.4(H)×9.9(V) mm |
| imlíne dim. | 40(H)×35.4(V) ×13(D) mm |
| limistéar bezel | 30.4(H)×13.9(V) mm |
| cóireáil | - |
| luminance | - |
| cóimheas codarsnachta | 10:1 (Typ.) (TM) |
| treo amharc | 6 o'clock |
| am freagartha | 150/150 (Typ.)(Tr/Td) |
| uillinn féachana | - |
| modh oibriúcháin | STN, Yellow/Green (Positive), Transflective |
| dath tacaíochta | Monochrome |
| foinse solais | YG-LED , 20K hours , W/O Driver |
| meáchan | - |
| deartha le haghaidh | Instruments & Meters |
| ráta fhráma | - |
| painéal tadhaill | Without |
| cineál comhéadan | 8-bit parallel , 16 pins Pad |
| soláthar leictreachas | 5.0V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
