| Uimhir Pháirt | FC0801A04-RNNYBW-16LE |
| Branda | Fordata |
| Méid | 2.3 |
| Iarratas | Instruments & Me |
| Rún | 5×8 |
| Comhdhéanamh | STN-LCD, LCM |
| Gile | |
| CR | 10:1 |
| Dathanna | Monochrome |
| Cúlsolas | No |
| Comhéadan | |
| branda | Fordata |
| Mionsamhail | FC0801A04-RNNYBW-16LE |
| méid trasnánach | 2.3 inch |
| cineál | STN-LCD, LCM |
| formáid charn | 5×8 dots |
| méid cló | 6.45×10.75 mm |
| páirc cló | 7.15×10.75 mm |
| limistéar gníomhach | 56.5(H)×10.75(V) mm |
| imlíne dim. | 84(H)×44(V) ×10(D) mm |
| limistéar bezel | 61.0(H)×15.8(V) mm |
| cóireáil | - |
| luminance | - |
| cóimheas codarsnachta | 10:1 (Typ.) (TM) |
| treo amharc | 6 o'clock |
| am freagartha | 150/150 (Typ.)(Tr/Tf) |
| uillinn féachana | - |
| modh oibriúcháin | STN, Yellow/Green (Positive), Reflective |
| dath tacaíochta | Monochrome |
| foinse solais | No B/L |
| meáchan | - |
| deartha le haghaidh | Instruments & Meters |
| ráta fhráma | - |
| painéal tadhaill | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
