| Uimhir Pháirt | EV101WUM-N20 |
| Branda | BOE |
| Méid | 10.1 |
| Iarratas | Medical Imaging |
| Rún | 1920×1200 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | BOE |
| Mionsamhail | EV101WUM-N20 |
| méid trasnánach | 10.1 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1920(RGB)×1200 [WUXGA] 224PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 216.806(H)×135.504(V) mm |
| imlíne dim. | 229.45(H)×149.22(V) mm |
| luminance | 600 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 30 (Typ.)(Tr+Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| modh oibriúcháin | ADS, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 72% NTSC |
| foinse solais | WLED , W/O Driver |
| meáchan | - |
| deartha le haghaidh | Medical Imaging |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 45 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -25 ~ 80 °C |
