| Uimhir Pháirt | DMF-50174 |
| Branda | OPTREX |
| Méid | 5.7 |
| Iarratas | Industrial |
| Rún | 320×240 |
| Comhdhéanamh | STN-LCD, LCM |
| Gile | |
| CR | |
| Dathanna | Monochrome |
| Cúlsolas | CCFL |
| Comhéadan | Parallel |
| branda | OPTREX |
| Mionsamhail | DMF-50174 |
| méid trasnánach | 5.7 inch |
| cineál | STN-LCD, LCM |
| formáid picteilín | 320×240 [QVGA] 70PPI |
| cumraíocht | Rectangle |
| limistéar gníomhach | 115.17(H)×86.37(V) mm |
| imlíne dim. | 174(H)×112(V) ×14(D) mm |
| limistéar bezel | 122.0(H)×92.0(V) mm |
| cóireáil | - |
| treo amharc | - |
| am freagartha | - |
| uillinn féachana | - |
| modh oibriúcháin | STN |
| dath tacaíochta | Monochrome |
| foinse solais | CCFL , W/O Driver |
| meáchan | - |
| deartha le haghaidh | Industrial |
| ráta fhráma | 70Hz |
| painéal tadhaill | Without |
| cineál comhéadan | Parallel Data (1ch, 4-bit) , 14 pins Connector |
| soláthar leictreachas | 5.0V (Typ.) |
| timpeallacht | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| C555001 | SII | 5.7 | 320×240 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| DMF-50174ZNB-FW | Kyocera | 5.7 | 320×240 |
| DMF-50773NB-FW | Kyocera | 5.4 | 240×128 |
| DMF-50773NF-FW | Kyocera | 5.4 | 240×128 |
| DMF-50840NB-FW | Kyocera | 5.7 | 320×240 |
| DMF-51043NFU-FW-1 | Kyocera | 9.4 | 640×480 |
| LTA057A344F | TOSHIBA | 5.7 | 320×240 |
| TCG057QVLAC-G00 | Kyocera | 5.7 | 320×240 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
