| Uimhir Pháirt | DLC1040ABG-3 |
| Branda | Other |
| Méid | 10.4 |
| Iarratas | IA |
| Rún | 800×600 |
| Comhdhéanamh | LCM |
| Gile | 1000 |
| CR | 800:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | DLC |
| múnla painéil | DLC1040ABG-3 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 10.4 inch |
| taifeach | 800(RGB)×600 , SVGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 211.2×158.4 mm |
| imlíne | 236×176.9×5.9 mm |
| dromchla | |
| gile | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193153% |
| am freagartha | 30 (Typ.)(Tr+Td) |
| uillinn féachana | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | WLEDWithout Driver |
| comhéadan comhartha | LVDS (1 ch, 6-bit), 20 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | IA |
