| Uimhir Pháirt | DLC0560AIG-3 |
| Branda | Other |
| Méid | 5.6 |
| Iarratas | IA |
| Rún | 640×480 |
| Comhdhéanamh | LCM |
| Gile | 800 |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | TTL |
| branda painéil | DLC |
| múnla painéil | DLC0560AIG-3 1 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 5.6 inch |
| taifeach | 640(RGB)×480 , VGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 112.896×84.672 mm |
| imlíne | 126.5×100×6 mm |
| dromchla | Antiglare |
| gile | 800 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit) |
| am freagartha | 10/15 (Typ.)(Tr/Td) |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | WLEDEmbedded (LED Driver) |
| comhéadan comhartha | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | IA |
