| Uimhir Pháirt | CT024TN02 V.6 |
| Branda | Innolux |
| Méid | 2.4 |
| Iarratas | Mobile Phone |
| Rún | 240×320 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 300:1 |
| Dathanna | 65K |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | Innolux |
| Mionsamhail | CT024TN02 V.6 |
| méid trasnánach | 2.4 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 240(RGB)×320 [QVGA] 166PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 36.72(H)×48.96(V) mm |
| imlíne dim. | - |
| luminance | - |
| cóimheas codarsnachta | 300:1 (Typ.) (TM) |
| treo amharc | 12 o'clock |
| am freagartha | 30 (Typ.)(Tr+Td) |
| uillinn féachana | 45/45/50/20 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 65K 60% NTSC |
| foinse solais | WLED |
| meáchan | - |
| deartha le haghaidh | Mobile Phone |
| ráta fhráma | - |
| painéal tadhaill | 4-wire Resistive Touch |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
