| Uimhir Pháirt | CM546B2-001 |
| Branda | CSOT |
| Méid | 5.5 |
| Iarratas | Mobile Phone |
| Rún | 1080×1920 |
| Comhdhéanamh | LTPS TFT-LCD, CELL |
| Gile | |
| CR | 1500:1 |
| Dathanna | 16.7M |
| Cúlsolas | No |
| Comhéadan | |
| branda painéil | CSOT |
| múnla painéil | CM546B2-001 |
| méid an phainéil | 5.5" |
| cineál painéil | LTPS TFT-LCD, CELL |
| taifeach | 1080(RGB)×1920, FHD, 403PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 68.04(W)×120.96(H) mm |
| oscailt bezel | - |
| méid imlíne | 69.44(W)×126.81(H) ×0.45(D) mm |
| dromchla | With Polarizer |
| gile | 0 cd/m² |
| cóimheas codarsnachta | 1500:1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| mód taispeána | FFS, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 35 (Typ.)(Tr+Td) |
| doimhneacht gloine | 0.15+0.15 mm |
| transmissivity | 4.69% (Typ.)(with APCF) |
| dathanna a thaispeáint | 16.7M 80% NTSC |
| cineál lampa | No B/L |
| minicíocht | - |
| scáileán tadhaill | In-Cell Touch |
| Tiománaí ic | COG Built-in TD4310 |
| meáchan painéal | TBD |
| iarratas | Mobile Phone |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| E555HBM2 | EDO | 5.5 | 720×1280 |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LM6Q35 | SHARP | 5.5 | 320×240 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| TM055JDHP71 | Tianma | 5.5 | 720×1280 |
