| Uimhir Pháirt | CLAA154WB08AN |
| Branda | CPT |
| Méid | 15.4 |
| Iarratas | NBPC |
| Rún | 1280×800 |
| Comhdhéanamh | LCM |
| Gile | 220 |
| CR | 350:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | LVDS |
| branda painéil | CPT |
| múnla painéil | CLAA154WB08AN 20 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 15.4 inch |
| taifeach | 1280(RGB)×800 , WXGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 331.2×207 mm |
| imlíne | 344×222×6.2 mm |
| stíl cruth | Wedge (PCBA Bent, Depth ≥5.2mm) |
| dromchla | Glare (Haze 0%), Hard coating (3H) |
| gile | 220 cd/m² (Typ.) |
| cóimheas codarsnachta | 350:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193150% |
| am freagartha | 6/10 (Typ.)(Tr/Td) |
| uillinn féachana | 45/45/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 1 pcsCCFLWithout Driver |
| comhéadan comhartha | LVDS (1 ch, 6-bit), 30 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | NBPC |
| CLAA150XA03 | CPT | 15.0 | 1024×768 |
| CLAA150XM05 | CPT | 15.0 | 1024×768 |
| CLAA150XP01Q V2 | CPT | 15.0 | 1024×768 |
| CLAA154WB04N | CPT | 15.4 | 1280×800 |
| CLAA154WB08AN | CPT | 15.4 | 1280×800 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| CLAA156WA01A | CPT | 15.6 | 1366×768 |
| CLAA156WA11A | CPT | 15.6 | 1366×768 |
| CLAA156WA15A | CPT | 15.6 | 1366×768 |
| CLAA156WB11A | CPT | 15.6 | 1366×768 |
| B101EW01 V1 | AUO | 10.1 | 1280×720 |
| B133XW03 V4 | AUO | 13.3 | 1366×768 |
| B141XN03 V0 | AUO | 14.1 | 1024×768 |
| FLC31SVC6S-17 | Fujitsu | 12.1 | 800×600 |
| LP154WX4-TLC8 | LG Display | 15.4 | 1280×800 |
| LP156WH3-TLE1 | LG Display | 15.6 | 1366×768 |
| LQ156D1JX01 | SHARP | 15.6 | 3840×2160 |
| LTD121EW6S | TOSHIBA | 12.1 | 1280×800 |
| LTN170X2-L03 | Samsung | 17.0 | 1440×900 |
| M156NWR1 R0 | IVO | 15.6 | 1366×768 |
