| Uimhir Pháirt | CLAA123PA02CW |
| Branda | CPT |
| Méid | 12.3 |
| Iarratas | Industrial Outdoor H |
| Rún | 1440×540 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | CPT |
| Mionsamhail | CLAA123PA02CW |
| méid trasnánach | 12.3 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1440(RGB)×540 125PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 291.6(H)×109.35(V) mm |
| imlíne dim. | 312.9(H)×132.2(V) ×19.2(D) mm |
| limistéar bezel | 294.8(H)×112.4(V) mm |
| cóireáil | Antiglare (Haze 25%) |
| luminance | 800 cd/m² (Typ.) |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| treo amharc | 6 o'clock |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 60/60/50/60 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 16.7M 70% NTSC |
| foinse solais | WLED [8S3P] , 30K hours , W/O Driver |
| meáchan | 510g (Typ.) |
| deartha le haghaidh | Industrial Outdoor High Brightness Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 30 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
