| Uimhir Pháirt | CLAA101WK07 XN |
| Branda | CPT |
| Méid | 10.1 |
| Iarratas | Automotive Display |
| Rún | 1280×720 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 900:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | CPT |
| méid trasnánach | 10.1 inch |
| formáid picteilín | 1280(RGB)×720 [WXGA] 144PPI |
| limistéar gníomhach | 224.64(H)×126.36(V) mm |
| limistéar bezel | 227.64(H)×129.36(V) mm |
| luminance | 600 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| dath tacaíochta | 262K/16.7M 70% NTSC |
| meáchan | 430g (Typ.) |
| ráta fhráma | 60Hz |
| Mionsamhail | CLAA101WK07 XN |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 238.8(H)×148.05(V) ×8.7(D) mm |
| cóireáil | Antiglare (Haze 25%), Hard coating (3H) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| am freagartha | 25 (Typ.)(Tr+Td) |
| modh oibriúcháin | HFFS, Normally Black, Transmissive |
| foinse solais | WLED [6S5P] , 30K hours , W/O Driver |
| deartha le haghaidh | Automotive Display |
| painéal tadhaill | Without |
