| Uimhir Pháirt | CLAA080WK0A XN |
| Branda | CPT |
| Méid | 8.0 |
| Iarratas | Automotive Display |
| Rún | 1280×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | CPT |
| Mionsamhail | CLAA080WK0A XN |
| méid trasnánach | 8.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1280(RGB)×720 [WXGA] 183PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 177.024(H)×99.576(V) mm |
| imlíne dim. | 182.8(H)×116.9(V) ×6.8(D) mm |
| limistéar bezel | 179.024(H)×101.576(V) mm |
| cóireáil | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 600 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| modh oibriúcháin | HFFS, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 70% NTSC |
| foinse solais | WLED [9S3P] , 50K hours , W/O Driver |
| meáchan | 120/230g (Typ./Max.) |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
