| Uimhir Pháirt | C123VAN01.0 |
| Branda | AUO |
| Méid | 12.3 |
| Iarratas | Automotive Display |
| Rún | 1440×540 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | |
| Dathanna | 16.7M |
| Cúlsolas | - |
| Comhéadan | RSDS |
| branda painéil | AUO |
| méid an phainéil | 12.3" |
| taifeach | 1440(RGB)×540, 125PPI |
| limistéar taispeána | 291.6(W)×109.35(H) mm |
| méid imlíne | 308.5(W)×129(H) mm |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M |
| minicíocht | 60Hz |
| meáchan painéal | 580±58g |
| comhéadan comhartha | RSDS (1 Channel) FPC |
| timpeallacht | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
| múnla painéil | C123VAN01.0 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 294.8(W)×112.35(H) mm |
| dromchla | Antiglare, Hard coating (3H) |
| mód taispeána | AHVA, Normally Black, Transmissive |
| am freagartha | - |
| cineál lampa | |
| scáileán tadhaill | Without |
| iarratas | Automotive Display |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
