| Uimhir Pháirt | C123HAN02.5 |
| Branda | AUO |
| Méid | 12.3 |
| Iarratas | Automotive Display |
| Rún | 1920×720 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 8S4P |
| Comhéadan | |
| monaróir | AUO |
| ainm samhail | C123HAN02.5 |
| méid scáileáin | 12.3 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1920(RGB)×720 167PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 292.032 × 109.512 (H×V) |
| imlíne (mm) | 310.75 × 129.86 × 16.23 (H×V×D) |
| limistéar bezel (mm) | 293.94 × 111.42 (H×V) |
| cóireáil | Antiglare |
| luminance | 600 cd/m² (Min.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| freagra | 15/45 (Typ.)(Tr/Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | AHVA, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 75% NTSC |
| cúlsolas | 8S4P WLED , 10K hours , No Driver |
| mais | 570±57g |
| a úsáidtear le haghaidh | Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
