| Uimhir Pháirt | C101EAN01.1 |
| Branda | AUO |
| Méid | 10.1 |
| Iarratas | Automotive Display |
| Rún | 1280×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda painéil | AUO |
| múnla painéil | C101EAN01.1 |
| méid an phainéil | 10.1" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1280(RGB)×720, WXGA, 145PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 223.68(W)×125.82(H) mm |
| oscailt bezel | - |
| gile | - |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| mód taispeána | AHVA, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 20/20 (Max.)(Tr/Td) |
| dathanna a thaispeáint | 16.7M |
| cineál lampa | WLED |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | - |
| iarratas | Automotive Display |
| timpeallacht | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| BT101IW01 V.0 | Innolux | 10.1 | 1024×600 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| G101STN01.0 | AUO | 10.1 | 1024×600 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| LP101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LTL101AL06-003 | Samsung | 10.1 | 1280×800 |
| LTN101NT02-L01 | Samsung | 10.1 | 1024×600 |
