| Uimhir Pháirt | C100HAT01.0 |
| Branda | AUO |
| Méid | 10.0 |
| Iarratas | Automotive Display |
| Rún | 1560×700 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| monaróir | AUO |
| ainm samhail | C100HAT01.0 |
| méid scáileáin | 10.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1560(RGB)×700 171PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 231.66 × 103.95 (H×V) |
| imlíne (mm) | 259.36 × 131.32 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare, Antireflection |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| freagra | 30 (Max.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | AHVA, Normally Black, Transmissive |
| doimhneacht dath | 16.7M |
| cúlsolas | WLED |
| mais | 375±38g |
| a úsáidtear le haghaidh | Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | - |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
