| Uimhir Pháirt | C090EAN04.1 |
| Branda | AUO |
| Méid | 9.0 |
| Iarratas | Outdoor High Brightn |
| Rún | 1280×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AUO |
| Mionsamhail | C090EAN04.1 |
| méid trasnánach | 9.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1280(RGB)×720 [WXGA] 163PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 198.72(H)×111.78(V) mm |
| imlíne dim. | 212.2(H)×127.9(V) ×11(D) mm |
| limistéar bezel | 202.02(H)×115.78(V) mm |
| cóireáil | Antiglare |
| luminance | 900 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 30 (Typ.)(Tr+Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| modh oibriúcháin | AHVA, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 72% NTSC |
| foinse solais | WLED [8S3P] , 10K hours , W/O Driver |
| meáchan | TBD |
| deartha le haghaidh | Outdoor High Brightness Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 40 pins FPC |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
