| Uimhir Pháirt | C090EAN01.0 |
| Branda | AUO |
| Méid | 9.0 |
| Iarratas | Automotive Display |
| Rún | 1280×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AUO |
| Mionsamhail | C090EAN01.0 |
| méid trasnánach | 9.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1280(RGB)×720 [WXGA] 163PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 198.72(H)×111.78(V) mm |
| imlíne dim. | - |
| luminance | - |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 15/15 (Max.)(Tr/Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| modh oibriúcháin | AHVA, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 70% NTSC |
| foinse solais | WLED |
| meáchan | - |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
