| Uimhir Pháirt | C084XAN01.0 |
| Branda | AUO |
| Méid | 8.4 |
| Iarratas | Automotive Display |
| Rún | 1024×768 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| monaróir | AUO |
| méid scáileáin | 8.4 inch |
| uimhir picteilín | 1024(RGB)×768 (XGA) 152PPI |
| limistéar gníomhach(mm) | 170.496 × 127.872 (H×V) |
| luminance | - |
| uillinn féachana | - |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M |
| mais | - |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (1 ch, 8-bit) , 40 pins Connector |
| uas. rátálacha | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| ainm samhail | C084XAN01.0 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | - |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| freagra | 30 (Max.)(Tr+Td) ms |
| modh oibre | AHVA, Normally Black, Transmissive |
| cúlsolas | WLED |
| a úsáidtear le haghaidh | Automotive Display |
| scáileán tadhaill | Without |
