| Uimhir Pháirt | C080VTN04.0 |
| Branda | AUO |
| Méid | 8.0 |
| Iarratas | Automotive Display |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| branda | AUO |
| Mionsamhail | C080VTN04.0 |
| méid trasnánach | 8.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 800(RGB)×480 [WVGA] 115PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 175.2(H)×105.12(V) mm |
| imlíne dim. | - |
| limistéar bezel | - |
| cóireáil | Antiglare |
| treo amharc | - |
| am freagartha | 15/20 (Typ.)(Tr/Td) |
| uillinn féachana | 60/60/40/60 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K |
| foinse solais | WLED |
| meáchan | - |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | - |
| cineál comhéadan | Parallel RGB (1 ch, 6-bit) , 60 pins Connector |
| timpeallacht | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
