| Uimhir Pháirt | C042FAN01.8 |
| Branda | AUO |
| Méid | 4.2 |
| Iarratas | Outdoor High Brightn |
| Rún | 480×272 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K |
| Cúlsolas | 3S2P |
| Comhéadan | |
| monaróir | AUO |
| ainm samhail | C042FAN01.8 |
| méid scáileáin | 4.2 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 480(RGB)×272 (WQVGA) 131PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 92.88 × 52.632 (H×V) |
| imlíne (mm) | 102.8 × 68.52 × 20 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare |
| luminance | 700 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Min.)(CR≥10) |
| freagra | 13/14 (Typ.)(Tr/Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | AHVA, Normally Black, Transmissive |
| doimhneacht dath | 262K 71% NTSC |
| cúlsolas | 3S2P WLED , 10K hours , No Driver |
| mais | 89.8g (Typ.) |
| a úsáidtear le haghaidh | Outdoor High Brightness Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
