| Uimhir Pháirt | B173HAN01.4 |
| Branda | AUO |
| Méid | 17.3 |
| Iarratas | Laptop Gaming |
| Rún | 1920×1080 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 16.2M |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| branda painéil | AUO |
| múnla painéil | B173HAN01.4 (AUO149D) |
| méid an phainéil | 17.3" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1920(RGB)×1080, FHD, 127PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 381.888(W)×214.812(H) mm |
| oscailt bezel | - |
| méid imlíne | 398.1(W)×250.5(H) ×4(D) mm |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 300 cd/m² (Typ.) |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | AHVA, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 16.2M 72% NTSC |
| cineál lampa | WLED , 15K hours , With LED Driver |
| minicíocht | 120Hz |
| scáileán tadhaill | Without |
| stíl cruth | Flat (PCBA Flat, T3.4~4.0mm) |
| iarratas | Laptop Gaming |
| comhéadan comhartha | eDP (4 Lanes) , eDP1.4a , 40 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B173HAN01.0 | AUO | 17.3 | 1920×1080 |
| B173HTN01.1 | AUO | 17.3 | 1920×1080 |
| B173HW01 V4 | AUO | 17.3 | 1920×1080 |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| B173HW02 V1 | AUO | 17.3 | 1920×1080 |
| B173RW01 V3 | AUO | 17.3 | 1600×900 |
| HSD173PUW1-A00 | HannStar | 17.3 | 1920×1080 |
| LP173WF2-TPB1 | LG Display | 17.3 | 1920×1080 |
| LP173WF3-SLB2 | LG Display | 17.3 | 1920×1080 |
| N173FGE-L23 | Innolux | 17.3 | 1600×900 |
