| Uimhir Pháirt | B125XTN01.0 HW1A |
| Branda | AUO |
| Méid | 12.5 |
| Iarratas | Laptop |
| Rún | 1366×768 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 400:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| branda painéil | AUO |
| múnla painéil | B125XTN01.0 HW1A (AUO106C) |
| méid an phainéil | 12.5" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1366(RGB)×768, WXGA, 125PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 276.615(W)×155.52(H) mm |
| oscailt bezel | - |
| méid imlíne | 300.4(W)×181.4(H) ×3(D) mm |
| dromchla | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| gile | 200 cd/m² (Typ.) |
| cóimheas codarsnachta | 400:1 (Typ.) (TM) |
| uillinn féachana | 45/45/15/35 (Typ.)(CR≥10) |
| mód taispeána | TN, Normally White, Transmissive |
| radharc is fearr ar | 6 o'clock |
| am freagartha | 16 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 262K 45% NTSC |
| cineál lampa | WLED , 15K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| stíl cruth | Slim (PCBA Flat, T≤3.2mm) |
| iarratas | Laptop |
| comhéadan comhartha | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B125HAN01.0 | AUO | 12.5 | 1920×1080 |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| HB125WX1-200 | BOE | 12.5 | 1366×768 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB2 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| M125NWR3 R0 | IVO | 12.5 | 1366×768 |
| NV125QUM-N81 | BOE | 12.5 | 3840×2160 |
